This connector fits the older style Yamaha Waverunners Ride motor on the engine harness side.
A complete kit contains
1 connector N13
16 seals A50
16 contacts + 1 extra B35
12 cavity plugs A52
The S7Plus is our newest management system offering 22 x Inputs, 16 x Fuel Outputs, 8 x H-Bridge Outputs 6 x Ignition Outputs, 2 x Lambda Input, 2 x Knock Input, 2 x EGT Input and Main Relay Control. All software features are enabled from factory except for Direct Injection control and Paddle-Shift control which is an optional upgrade
The S7-Plus ECU offers an extremely high level of precise engine management control. The triple processor unit uses a high speed RISC processor for code execution and an additional large FPGA for high speed engine position tracking, allowing the scheduling of code to be independent of signal patterns, increasing flexibility, efficiency and accuracy under transient conditions. This powerful combination also allows advanced control algorithms but yet easy to map for the end user still using our SCal software and S7 Firmware.Designed to cater for PnP kits where clients also need the programmable CAN Bus and Drive-By-Wire support offered by the S7-Plus.
The third processor present is available for in the future users to write their own code in C for Full Vehicle Integration via Canbus and Build some custom strategies to handle some of the unique requirements which are now found in OEM Applications. Currently only Syvecs staff can do this but we are working on offering this out to all our dealers very soon!Cased In A Sealed Aluminium Billet Unit With 3 x Waterproof Connectors Offering 94pinsInputs22 x General Purpose Analogue Inputs:10 x 5V/Bipolar, Sensor/Sync/Speed, Programmable Trigger Voltages4 x 5V/Thermistor, Sensor/Sync/Speed, Fixed Trigger Voltages4 x 5V Sensor Input4 x Thermistor Sensor Input2 x NTK / LSU4.9 / Denso AF Lambda Inputs1 x K-Type Thermocouple Circuit (Two Available if not use 2nd Canbus)2x Knock InputOutputs30 x High/Low Side Driver Outputs:8 x Half Bridge Outputs (Max 10 Amps)16 x Low Side Injection/PWM Outputs (Max 10 Amps)6 x TTL / IGBT Ignition DriversMain Relay Control Circuit with Wake on Can SupportComms3 x Can 2.0B – (3rd CanBus takes over EGT1 Pins and not programmable from Scal, Custom Use only)1 x Rs232 Output1 x Kline Output100 Mhz Full Duplex Ethernet For Connection To PC For Programming And Data Download
32mb Onboard Logging memory6 to 20v input voltage range with reverse polarity protection3 x regulated 5V sensor supply outputs with protectionOperating Temperature -55 to +125 CDimensions : 185 X 145 X 55 mm
The absolute best SeaDoo plug and play fuel pump controller on the market. Completely waterproof, will not void the warranty and does not rely on fuses. Automatic overcurrent protection and channel retry means it will never leave you stranded in the middle of the ocean in case of an overheating pump.
Made in the USA with all OEM connectors and completely sealed in a CNC aluminum case. Can be mounted in any position and will drive any electrical brushed fuel pump on the market.
Smaller that any conventional relay and has a built-in RGB led for easy visual inspection. Comes with instructions and can be mounted in any position.
This connector is intended to keep the harness waterproof in applications that use the OEM Yamaha CAN bus based dash for display. Since the OEM dash connects directly to the buzzer, the connector on the harness needs a sealing plug to remain waterproof.
See main harness instructions for how to use this connector.
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
This connector is intended to keep the harness waterproof in applications that do not have a flex fuel sensor installed
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
This connector is intended to keep the harness waterproof in applications that do not have a Haltech dash installed
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
This connector is intended to keep the harness waterproof in applications that do not have a knock sensor installed
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
This connector is intended to keep the harness waterproof in applications that do not have an oil pressure sensor installed
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
Ensures the harness stays waterproof when not using a rotary trim pot.
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
Ensures the harness stays waterproof when not using a secondary fuel pump.
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
Yamaha FZR series main harness
Keeps the main harness waterproof for applications that do not use a spare switch
Fits:
Yamaha GP1800 series main harness
Yamaha FX series main harness
As supplied this product is direct Plug 'n' Play compatible with a NEXUS VCU, an Elite ECU CAN port, Elite ECU Harness, CAN connector, or multiple CAN device installation using an Elite 4 Port CAN HUB.
Suits: Elite and NEXUS Series ECUs only
Includes: Eight Channel Thermocouple Amplifier, CAN cable, DTM-4 to Circular Connector Cable 1200mm / 4ft, Quick Start Guide
Notes: Thermocouple Probes Sold Separately
Yamaha WaveRunner PWC throttle body connector kit. Engine harness side
This connector kit is a replacement for the engine harness side connector that attaches the main harness to the throttle body sub-harness.
A complete kit contains:
1 connector with lock G11
6 red seals A51
6 contacts B35
This harness connects to the voltage rectifier on Yamaha GP1800 and FX models 18+. It provides stable amperage and a clean installation. It works with our main harness and connects directly to the battery.
The Haltech CAN Wideband Controller allows the user to accurately measure air/fuel ratios over a wide range from rich to lean via the Haltech CAN system for precise engine tuning.
LENGTH: 1.2M (4ft)
INCLUDES: Single Channel, CAN Wideband Controller, 4.9LSU Sensor, CAN Cable (4'/1200mm), Power Supply Cable, Weld-on Bung, Quick Start Guide.
NOTES: The ideal CAN expansion accessory for all Elite Series ECUs.
Smaller, lighter and water-proof! The new Haltech Wideband Controller can now be safely fitted inside your engine bay.
Suits: NTK Sensor
Includes: Single Channel, CAN Wideband Controller, NTK Sensor, CAN Cable (4'/1200mm), Power Supply Cable, Weld-on Bung, Quick Start Guide.
Notes: Best product for methanol powered vehicles
The Haltech CAN Wideband Controller allows the user to accurately measure air/fuel ratios over a wide range from rich to lean via the Haltech CAN system for precise engine tuning
LENGTH: 1.2M (4ft)
INCLUDES: Dual Channel, CAN Wideband Controller, 2 x 4.9LSU Sensor, CAN Cable (4'/1200mm), Power Supply Cable, 2 x Weld-on Bung, Quick Start Guide.
NOTES: The ideal CAN expansion accessory for all Elite Series ECUs.
