The Haltech CAN Wideband Controller allows the user to accurately measure air/fuel ratios over a wide range from rich to lean via the Haltech CAN system for precise engine tuning.
LENGTH: 1.2M (4ft)
INCLUDES: Single Channel, CAN Wideband Controller, 4.9LSU Sensor, CAN Cable (4'/1200mm), Power Supply Cable, Weld-on Bung, Quick Start Guide.
NOTES: The ideal CAN expansion accessory for all Elite Series ECUs.
Smaller, lighter and water-proof! The new Haltech Wideband Controller can now be safely fitted inside your engine bay.
Suits: NTK Sensor
Includes: Single Channel, CAN Wideband Controller, NTK Sensor, CAN Cable (4'/1200mm), Power Supply Cable, Weld-on Bung, Quick Start Guide.
Notes: Best product for methanol powered vehicles
The Haltech CAN Wideband Controller allows the user to accurately measure air/fuel ratios over a wide range from rich to lean via the Haltech CAN system for precise engine tuning
LENGTH: 1.2M (4ft)
INCLUDES: Dual Channel, CAN Wideband Controller, 2 x 4.9LSU Sensor, CAN Cable (4'/1200mm), Power Supply Cable, 2 x Weld-on Bung, Quick Start Guide.
NOTES: The ideal CAN expansion accessory for all Elite Series ECUs.
Smaller, lighter and water-proof! The new Haltech Wideband Controller can now be safely fitted inside your engine bay
Suits: NTK Sensor
Includes: Dual Channel, CAN Wideband Controller, 2 x NTK Sensors, CAN Cable (4'/1200mm), Power Supply Cable, 2 x Weld-on Bung, Quick Start Guide.
Notes: Best product for methanol powered vehicles
Genuine NTK sensor modified by Haltech to improve sensor longevity and accuracy at extremely rich air to fuel ratios by the addition of a thin walled spring steel radial shroud at the sensor tip
Includes: 1 x NTK LZA08-H5 Wideband Sensor - modified
Suits: NEXUS Series devices and NTK WB1+WB2 CAN Wideband units.
Yamaha 1.8L waverunner accelerator position sensor (APS) connector kit for newer style GP1800 and other models.
Fits all Yamaha waverunner models with the newer integral pedal position sensor on the steering wheel.
A complete kit contains
1 APS Connector K12
9 seals A61
10 contacts B35
Yamaha 1.8L waverunner accelerator position sensor (APS) connector kit.
Fits all Yamaha waverunner models up to 2017 with cable driven 8-pin APS module mounted beneath steering column on the left side of the hull.
A complete kit contains
1 APS Connector G15
8 red seals A50
9 contacts B34
2 cavity seals A40
This harness completely replaces the OEM harness, ECU and fuse panel in the Yamaha WaveRunners GP1800 models from 2017-2022. We have perfected this design through years of racing and development. Completely waterproof when used as recommended and slim design packed with many features like:
Plugs to a Fueltech FT550 latest generation programmable ECU
4 primary injectors + 4 additional already in the harness (Used with our additional injector harness)
Boost control solenoid output
Ride control (Reverse)
Trim control
Bilge pump
Nitrous solenoid control
Nitrous bottle pressure
Oil pressure monitoring with adapter harness
Tunnel pressure monitoring via adapter harness
Compatible with OEM DBW throttle body. Compatible with Bosch throttle body via adapter harness
GPS input ready
Compatible with high impedance injectors only
Connects directly to a Nano wideband controller for use with LSU 4.2 sensor
1 Year limited warranty against manufacturing defects.
CAN bus expansion port for EGT or other Fueltech accessories.
External waterproof crank signal resistor easily changed for ultra-high RPM engines
Our harnesses have been winning races and setting records since 2011 and are a tested product. They come completely sealed with the basic functionality but can be easily expanded using our plug and play adapter harnesses in order to connect to any sensors the end user requires.
Full documentation and pinout is provided for easy troubleshooting as well as a complete catalog of every connector, contact and seal on our website.
We provide a base map with the purchase of every harness.
For applications that require additional functionality than what the base harness comes with, we recommend purchasing the correct adapter harnesses as well.
(Does not include ECU and Nano Wideband, sold separately)
Note: This harness completely eliminates the OEM display. Since the fuel level sensor is connected to the OEM display, it is up to the end user to reuse the fuel level connector and wire it up to our harness using the supplied connector pigtail.
This harness completely replaces the OEM harness in the Yamaha WaveRunners GP1800 models from 2017-2022. We have perfected this design through years of racing and development. Completely waterproof when used as recommended and slim design packed with many features like:
Plugs to a Haltech Nexus S2 latest generation programmable ECU
Boost control solenoid output
Ride control (Reverse)
Trim control
Auxiliary fuel pump support
Bilge pump
Compatible with OEM 2021+ dash and Haltech dash
Nitrous solenoid control
Nitrous bottle pressure
Oil pressure
Oil temperature
Tunnel pressure monitoring via adapter harness
Rotary trim input
Auxiliary switch input
Compatible with OEM DBW throttle body. Compatible with Bosch throttle body via adapter harness
Knock sensor control
Flex fuel sensor ready
GPS input ready
Can drive any type of injectors without any additional drivers.
Traction control and torque management
Rolling launch
Compatible with both Bosch and NTK wideband sensors
Ability to change 4 boost maps and 2 throttle feel maps directly from the OEM dash by using the original cruise control feature.
1 Year limited warranty against manufacturing defects.
CAN bus expansion port for EGT or other Haltech accessories.
These harnesses have been winning races since 2011 and are a tested product. They come completely sealed with the basic functionality but can be easily expanded using our plug and play adapter harnesses in order to connect to any sensors the end user requires.
Full documentation and pinout is provided for easy troubleshooting as well as a complete catalog of every connector, contact and seal on our website.
We provide a base map with the purchase of every harness.
For applications that require additional functionality than what the base harness comes with, we recommend purchasing the correct adapter harnesses as well.
